Model LSX2091X

• 20GHz Single Channel Microwave Signal Generator
• Frequency Resolution of 0.001Hz
• Phase noise of -134dBc/Hz at 1GHz, and -115dBc/Hz at 10GHz, at 10kHz carrier offset
• Max amplitude 10dBm Calibrated, 15dBm Settable
• Min amplitude -50dBm Calibrated, -70dBm Settable
• Amplitude Resolution of 0.01dB
• AM, FM, PM, Sweep & Pulse Modulation
• 2 slot PXIe module designed for maximum channel density in minimum rack space
• Multi instrument synchronization capability



Signal Integrity and Purity

One of the most important requirements in today’s testing and measurement applications is a high signal quality. With a typical SSB phase noise of -134dBc/Hz at 1GHz, and -115dBc/Hz at 10GHz, at 10kHz carrier offset, Tabor’s Lucid X Series platform delivers great quality signals with the best price to performance value.

Modulation Schemes

Signal bursts and chirps have become common need in most aerospace or defence application. With Tabor’s All-New Lucid Series, any signal modulation is possible, no matter if “narrow” or “standard” signals are required. On top of its outstanding pulse modulation performance, the Lucid Series is also equipped with many CW interferers, and modulated signals such as AM, FM, PM, Pulse, Pattern and Sweep.

Extremely Fast Switching

Time is a crucial factor, whether in design, on the production floor or inside ATE systems. With a switching speed of less than 500 µs (100 µs optional) at up to 20GHz, Tabor’s Lucid Series ensures maximum measurements at minimum time, setting the industry’s highest throughput standard.

Multiple Ways to Control the Unit and Write your Code

Tabor’s Lucid X Series comes with its own dedicated software to control the instrument functions, modes and features via a graphical user interface (GUI) as well as a complete set of drivers, allowing you to write your application in various environments including LabVIEW, Python, CVI, C++, VB and MATLAB. You may also link the supplied dll to other Windows-based API’s or use low-level SCPI commands to program the instrument, regardless of whether your application is written for Windows, Linux or Macintosh operating systems.



Model	Description
LSX2091X	20GHz Single Channel PXIe Microwave Signal Generator

 Options

Option	Description
PLS	Pulse Gennerator
PAT	Pattern Generator
LP	Low Power option to -80 dBm
FS	Fast Switching option 100us
EMU	Emulator Pack includes emulators for Keysight, R&S, Anapico & Holzworth
STN	Lucid X desktop holder. Designed to hold the module upright.
WE	1 year warranty extension (standard warranty 3 years)

Note: Options and Accessories must be specified at the time of your purchase.
