21 Slot PXIe Based Chassis with Embedded Controller

The PXE21100 is a 3U, 19in, PXIe based, 21 slot, Gen 4 chassis, that supports the Tabor Proteus Family of AWGs, the TE330x family of PXIe RF amplifiers, and other modules that comply with the PXIe standard. The system includes as standard an embedded i5-13500E PC with an internal 128GB SSD drive, Display Port connection, USB interfaces for a mouse and keyboard, as well as control using USB-C and 2.5Gb Ethernet. The PC is upgradeable to an i9-13900E and 960GB SSD.

Relevant Documents
Data Sheet(3 MB)
Links
  • Maximize rack space with a high slot count - 21 PXIe slots in 19in 3U
  • Fastest available data transfer speeds with Gen 4 PCIe support
  • Built-in computer - i5-13500E, upgradable to i9-13900E
  • Multi-chassis sync with the PXE21106 - Synchronization Unit
  • Smart fan and chassis status monitoring
  • High Speed Connectivity - 2.5GbE, Rear panel RJ45 connector and 3 x USB 2.0 (type A), 1 x USB3.2Gen1 (type A)



Formfactor

Size 3U, 19in 438.8mm x 176.0mm x 449.5mm

Embedded Controller

CPU: i5-13500E, upgradable to i9-13900E RAM: 8GB, upgradable to 32GB SSD: 128GB, upgradable to 960GB

Backplane

Backplane - PCIe Gen 4 Slots - 21

Scale to Multiple Chassis

Connect multiple chassis for a fully synchronized and phase-coherent system. The dedicated PXE21106, Mesh controller can synchronize up to 6 chassis and enables data transfer between modules in different chassis. For more than 6 chassis simply connect multiple PXE21106 units.

Model Description
PXE21100 21 Slots Chassis.

Options

Name Description
COMP Upgrade to i9-13900E and 960GB SSD.

Accessories

Name Description
SLOT1 Single Width - Blank Slot Covers (Required for cooling)
PXE21106 Multi-Channel Mesh, Synchronization Unit

Note: Options and Accessories must be specified at the time of your purchase.
